HySecurity Gate SWGO, 12VDC, ground mnt. to 20'

The HySecurity Vanguard 3501 Swing is a 12VDC battery-powered residential swing gate operator engineered for rural, ranch, residential, and HOA properties. Its low profile post mount design allows for compact installation, while the durable, corrosion-resistant enclosure and all-weather performance make it well suited to demanding outdoor environments. The system is easy to install and low maintenance, and is perfect for AC or solar applications. (Battery required for operation, not included.)

This electromechanical operator handles gate leaves up to 20 ft (6 m) long and up to 1,000 lb (272 kg), with adjustable open/close timing and slowdown positions. The offset pivot arm is designed to reduce the possibility of pinching. The operator supports single or dual gate applications, with a secondary drive chassis kit required for dual operation.

At its core is the advanced 1050 control board, which is simple to install and configure, offers an LCD display for detailed user feedback, an internal 7-day programmable timer, and surge protection. Nice BlueBUS 2-wire technology self-identifies monitored photo eyes, and a built-in solar regulator and charger with smart battery charging management supports off-grid and backup power needs. A wide range of optional accessories—keypads, photo eye kits, transmitters, solar panels, edge sensors, and programmers—is available to tailor the system to your site.

• Operating voltage: 12VDC (input voltage 12–30VDC); idle current 10mA
• Handles gate leaves up to 20 ft (6 m) and up to 1,000 lb (272 kg)
• Open/close time (to 90°): 12–20 seconds with adjustable slowdown positions
• Temperature rating: -4° to 122° F (-20° to 50° C) for all-weather performance
• Advanced 1050 control board: over 100 configurable parameters, 2 programmable relays, BlueBUS and Oview programmer port
• Supports up to 1,000 Inti or Era One remotes with rolling-code security
• Powder coated steel chassis and molded polyethylene cover; ETL Listed (UL 325) Usage Class I, II; 3-year warranty with product registration
