All-O-Matic 1/2 HP DC SLIDE GATE OPERATOR - RESIDENT

The All-O-Matic SL-45DC PRO is a 1/2 HP DC slide gate operator engineered for residential applications. Powered by a 24 VDC brushless motor with a planetary gearbox, it is designed to handle gates up to 800 lbs. and 30 feet in length, with an adjustable gate speed of 6" to 12" per second. The unit ships with the AOM-RED EYE and includes a back-drivable gearbox for push-open emergency release in the event of a power failure.

At the heart of the operator is the ALL-BLDC PRO control board, featuring an LCD display with on-board diagnostics, digital adjustments, auto-close timer, and obstruction sensing. It offers integrated wireless primary/secondary operation, a partial open option, programmable auxiliary inputs, a USB port for extracting diagnostic data and applying firmware updates, a built-in volt meter through the LCD display, a cycle counter, and more. The operator is solar ready and runs on 115/230 VAC single phase or a 24 VDC solar panel.

With integrated battery backup and an intermittent duty cycle, the SL-45DC PRO is suited to homes and properties requiring reliable slide gate automation across a wide temperature range. A range of accessories is available, including fire boxes, a 24V solar panel, goosenecks, V-groove wheels, and guide rollers.

• 24 VDC brushless motor with planetary gearbox; approx. 24:1 gearbox ratio
• Max gate weight 800 lbs. and max gate length 30 feet
• Adjustable gate speed of 6"-12" per second; intermittent duty cycle
• Power options: 115/230 VAC single phase and 24 VDC solar panel; 20 amp dedicated breaker required
• Integrated battery backup with (2) 7Ah 12VDC batteries; 250 cycles on a 600 lb. gate
• ALL-BLDC PRO control board with LCD display, on-board diagnostics, USB port, auto-close timer, and obstruction sensing
• Operating temperature range of -40 to 160°; 5 year residential warranty
